◆End-Face Grinding with Dual-Speed Capability: Employs end-face grinding technology, offering two linear speed options—40 m/s and 60 m/s—to efficiently process both cemented carbide and Stellite materials.
◆Advanced Four-Axis CNC System: Equipped with a Japanese four-axis CNC system, facilitating straightforward and intuitive operation. Users can directly set grinding cycles and feed rates via the human-machine interface.
◆High Precision Grinding: Achieves grinding accuracy up to 0.02 mm, aligning with the performance standards of imported machinery.
◆Fully Enclosed Automated Operation: Features a fully enclosed, automated system that maintains a clean workspace, enabling a single operator to efficiently manage multiple machines.
• Saw blade Diameter: < 210mm
• Function: SIDE sharpening
• Precision: <0.02mm
• Pitch:<50mm
• Cooperation Company
Advantages of bandsaw grinding machine
• More precision- grinding precision: <0.02mm,be impressed by the higher accuracy.
• Higher efficiency & higher productivity
• More flexibility- for precision in any requirement;
• More Function- grinding SIDE of bandsaw tips
Technical Premeter
| Model |
KDS210 |
| Bandsaw Diameter |
20~210mm |
| Bandsaw Thickness |
0.5~5mm |
| Hook angle |
0°~ 7° |
| Side angle |
0°~ 5° |
| Side Relief |
0°~ 5° |
| Tooth pitch |
2-50mm |
| Tip length |
2-15mm |
| Wheel diameter |
Φ100~Φ32mm |
| Wheel speed |
3500~5800RPM |
| Working efficiency |
5~20S/Tip |
| Machining accuracy |
<0.02mm |
| Power |
4kw |
| Machine dimensions |
2100L*1200W*1800H; |
| Weight |
2100kg |
Configuration
| Ball Screw |
IF(Germany) |
| Roller Guide |
HIWIN(Taiwan) |
| Pneumatic Parts |
SMC(Japan) |
| Servo Motor |
Inovance |
| PLC |
Inovance ARM600 |
| Harmonic Drive |
Inovance |
FAQ
1. How can I select the most suitable saw blade grinding machine?
- An optimal grinding machine should offer high precision and ensure a long service life for the tools it processes.
2. What is the performance level of TORSEL's saw blade grinding machine?
- TORSEL's saw blade grinding machine delivers exceptional precision with an accuracy of less than 0.015mm, and its service life extends up to 7–15 years.
3. Which companies do you collaborate with?
