CNC TORSEL Circular Saw Blade Sharpening Service Woodworking

1
MOQ
22000~27000
Price
CNC TORSEL Circular Saw Blade Sharpening Service Woodworking
Features Gallery Product Description Request A Quote
Features
Specifications
FUNCTION: FACE ANGLE GRINDING
MAX DIA.: 120-800MM
THICKNESS: 0.5-10MM
HOOK ANGLE: -5°~30°
BEVEL ANGLE: -15°~15°
CIRCUMFERENTIAL RANGE: 0°~5°
TIPS LENGTH RANGE: 1~15MM
PITCH: 2~65MM
Grinding Wheel Speed: 3.5~20S/TIP
WHEEL GRINDING SPEED: 3500`5800RPM
WHEEL SIZE: 150*32*16MM
PRECISION: < 0.03MM
POWER: 4KW
DIMENSION: 1465*1180*1850MM (L*W*H)
WEIGHT: 1300KG
Highlight:

CNC circular saw blade sharpening service

,

TORSEL circular saw blade sharpening service

,

circular saw blade sharpening service woodworking
Basic Infomation
Place of Origin: MADE IN CHINA
Brand Name: TORSEL
Certification: CE,ISO 9001
Model Number: AF650
Payment & Shipping Terms
Packaging Details: Water Proof + Wood Carton
Delivery Time: 25-35DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000UNITS/A
Product Description



Product Description

AF650 CNC FACE ANGLE Grinding Machine for TCT TIPS FACE angle sharpening, it is more suitable for saw blade grinding & resharpening. This grinder is more smart for working.




• Saw blade Diameter: < 800mm
• Function: face angle sharpening
• Precision: <0.03mm
• Model: AF650
• Pitch:<65mm
• Cooperation Company
CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 0

  CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 1



CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 2

CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 3



Advantages of sawblade grinding machine
• More precision- grinding precision: <0.03mm,be impressed by the higher accuracy.

• Higher efficiency & higher productivity- shares higher level autoamatical operation;
• More flexibility- for precision in any requirement;
• More Function- grinding FACE ANGLE  of sawblade

CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 4



Technical Premeter

Model AF650
Saw Diameter 120~800mm
Plate Thickness 0.5~10mm
Hook Angle -5°~30°
Bevel Angle -15°~15°
Bore Diameter 12~120mm
Pitch 2~65mm
Tip Length 1`15mm
Wheel Power 0.75KW
Wheel Diameter 150*32*16mm
Wheel Bore 32mm
Wheel Linear Velocity 30m/s
Grinding Speed 2mm~10mm/s
Processing Efficiency 3.5~20 tip/min
Grinding Accuracy <0.03mm
Coolant Tank 70 L
Input Voltage 380V 50Hz(OR 220V60Hz)
Power Approx 4KW
Dimension 1465mm*1180mm*1850mm
Weight 1300kg


Configuration
Ball Screw IF(Germany)
Roller Guide HIWIN(Taiwan)
Pneumatic Parts SMC(Japan)
Servo Motor Inovance
PLC Inovance ARM600
Harmonic Drive Inovance



CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 5
CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 6
CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 7




FAQ

1. How to chooce best saw blade grinding machine?
- Best grinding machine process tools with higher precision & long service life.

2. How is the performance of TORSEL saw blade grinding machine?
- TORSEL saw blade grinding machine process tool with excellent precision <0.015mm,the service life is upto 7-15 years.

3. Whats your cooperation companys?

CNC TORSEL Circular Saw Blade Sharpening Service Woodworking 8
