Home /Products/Saw Blade Sharpening Equipment/CNC Precision Circular Saw Blade Grinding Machine / Grinder

CNC Precision Circular Saw Blade Grinding Machine / Grinder

1
MOQ
16000~25000
Price
CNC Precision Circular Saw Blade Grinding Machine / Grinder
Features Gallery Product Description Request A Quote
Features
Specifications
FUNCTION: FACE ANGLE GRINDING
MAX DIA.: 120-650MM
THICKNESS: 0.5-10MM
HOOK ANGLE: 0°~25°
TOP ANGLE: 8°~25°
CIRCUMFERENTIAL RANGE: 0°~5°
TIPS LENGTH RANGE: 1~15MM
PITCH: 2~65MM
Grinding Wheel Speed: 3.5~20S/TIP
WHEEL GRINDING SPEED: 3500`5800RPM
WHEEL SIZE: 125*32*25MM
PRECISION: < 0.02MM
POWER: 4KW
DIMENSION: 1630*1100*1950MM (L*W*H)
WEIGHT: 1500KG
BEVEL ANGLE: -45°~45°
Highlight:

CNC saw blade grinding machine

,

Precision saw blade grinding machine

,

Circular saw blade grinding machine
Basic Infomation
Place of Origin: MADE IN CHINA
Brand Name: TORSEL
Certification: CE,ISO 9001
Model Number: TFM650
Payment & Shipping Terms
Packaging Details: Water Proof + Wood Carton
Delivery Time: 25-35DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000UNITS/A
Product Description

Product Description



TFM 650 Circular Saw Blade Regrinding Equipment



Mainly specially designed for resharpening service center to resharpen TCT Saw Blade Sharpening Machine, mainly considering easier to operate, widely used in wood working & aluminum cutting saws top/face/bevel angle. It is the most econimic model to invest for resharpening service center.


High-level productivity & precision grinding machine for carbide tools.

CNC Precision Circular Saw Blade Grinding Machine / Grinder 0



Advantages of saw blade sharpener
• More precision- grinding precision: <0.025mm,be impressed by the higher accuracy.
• More efficiency- experienced productivity on a higher level
• More user comfort- simplify your work
• More flexibility-for precision in any requirement
• More Function- grinding TOP & FACE of saw blade



CNC Control- High Precision is flexible to control ultra-precision grinding as requirement.



CNC Precision Circular Saw Blade Grinding Machine / Grinder 1 CNC Precision Circular Saw Blade Grinding Machine / Grinder 2




3-D Graphics Grinding Machine

CNC Precision Circular Saw Blade Grinding Machine / Grinder 3






Technical Premeter
Saw Blade Diameter 110~650mm(Max700mm)
Hook Angle 0°~ -25°
Top Angle 8°~25°
Chamfer Angle of Top 45°~-45°
Chamfer Angle of Face 30°~-30°
Bore Diameter 12-120mm
Wheel Diameter 125mm*32mm
Wheel Speed 4000~5000r/min
Grinding Speed 1~20mm/s
Power 4KW
Dimensions 1630 *1100 *1950mm
Weight 1500kg


Configuration
Ball Screw IF(Germany)
Roller Guide HIWIN(Taiwan)
Pneumatic Parts SMC(Japan)
Servo Motor Inovance
PLC Inovance ARM600
Harmonic Drive Inovance


CNC Precision Circular Saw Blade Grinding Machine / Grinder 4
CNC Precision Circular Saw Blade Grinding Machine / Grinder 5


CNC Precision Circular Saw Blade Grinding Machine / Grinder 6






FAQ

1. How to chooce best saw blade grinding machine?
- Best grinding machine process tools with higher precision & long service life.

2. How is the performance of TORSEL saw blade grinding machine?
- TORSEL saw blade grinding machine process tool with excellent precision <0.015mm,the service life is upto 7-15 years.

3. Whats your cooperation companys?

CNC Precision Circular Saw Blade Grinding Machine / Grinder 7
